330880-28-20-038-00-02 Bently Nevada PROXPAC XL 8mm Probe

Bently Nevada 330880-28-20-038-00-02 PROXPAC XL Proximity Transducer

The Bently Nevada 330880-28-20-038-00-02 is a PROXPAC XL Proximity Transducer from the 3300 Series. This complete transducer system includes an 8 mm probe with multiple agency approvals and 38 mm probe penetration. It features 3/4-14 NPT mounting thread for industrial installation.

Technical Specifications

• Part Number: 330880-28-20-038-00-02
• Model: PROXPAC XL Proximity Transducer
• Manufacturer: Bently Nevada
• Condition: New & Original in Factory Packing
• Warranty: 12 Months Factory Warranty

Configuration Options

• Model: 330880 - PROXPAC XL Proximity Transducer
• Probe and Approvals: -28 - 3300 XL 8 mm probe with Multiple approvals
• Standoff Adapter: -00 - No standoff adapter
• Probe Penetration: -038 - 38 mm
• Fittings Kit: -00 - No fittings; two plugs and two washers
• Mounting Thread: -02 - 3/4-14 NPT

Probe Specifications

• Probe Diameter: 8 mm
• Probe Penetration Length: 38 mm
• Mounting Thread: 3/4-14 NPT
• Sensing Tip Material: Polyphenylene sulfide (PPS)
• Case Material: 300 series stainless steel
• Temperature Range: -35°C to +120°C (-31°F to +248°F)
• Pressure Rating: 2000 psi (138 bar) maximum

Electrical Specifications

• Supply Voltage: -24 Vdc nominal
• Gap Range: 0.25 mm to 2.3 mm (10 mils to 90 mils)
• Scale Factor: 7.87 mV/μm (200 mV/mil) typical
• Frequency Response: 0 to 10 kHz
• Linearity: ±1% over full temperature range
• Output Impedance: 50 Ω

Agency Approvals

• CSA: Class I, Division 2, Groups A, B, C, D
• ATEX: II 3 G Ex nA IIC T5 Gc
• IECEx: Ex nA IIC T5 Gc
• Multiple approvals for global hazardous locations

Kit Contents

• Two mounting plugs
• Two sealing washers
• No fittings included as specified

Key Features

• Complete PROXPAC XL transducer system
• 8 mm probe diameter for standard applications
• 38 mm probe penetration length
• 3/4-14 NPT mounting thread
• Multiple agency approvals (CSA, ATEX, IECEx)
• Includes two plugs and two washers
• Factory-sealed original packaging
• 12-month manufacturer warranty

Package Contents

• 1x Bently Nevada 330880-28-20-038-00-02 PROXPAC XL Transducer
• 2x mounting plugs
• 2x sealing washers
• Factory-sealed original packaging
• Ships via FedEx, UPS, or DHL

FAQ

• What is the full part number?
  330880-28-20-038-00-02 for PROXPAC XL Proximity Transducer.
• What probe diameter and penetration?
  8 mm probe with 38 mm penetration.
• What mounting thread is used?
  3/4-14 NPT mounting thread.
• What agency approvals are included?
  Multiple approvals: CSA, ATEX, IECEx.
• What comes in the fittings kit?
  Two plugs and two washers (no fittings).
• What is the temperature range?
  -35°C to +120°C (-31°F to +248°F).
