330904-00-15-70-12-00 Bently Nevada | 3300 NSv Probe

Bently Nevada 3300 NSv Proximity Probe with FluidLoc Technology

Full Part Number: 330904-00-15-70-12-00

Manufacturer: Bently Nevada | Condition: New & Original | Warranty: 12 Months

Specialized Configuration

Thread Type: M8X1 with protective armor
Unthreaded Length: 00 mm (code -00)
Case Length: 150 mm (code -15)
Cable Length: 7.0 meters (23.0 feet, code 70)
Connector System: Miniature coaxial ClickLoc with FluidLoc cable (code 12)
Certifications: No agency approvals required (code 00)

Enhanced Electrical Specifications

• Probe DC Resistance: 5.9Ω ±0.9Ω at 7m length
• FluidLoc Cable Resistance: Center 0.220Ω/m | Shield 0.066Ω/m
• Capacitance: 69.9 pF/m typical
• Frequency Response: 0-10 kHz (±3dB) with 305m wiring
• Insulation Resistance: >1000 MΩ at 500V DC

Robust Mechanical Design

• Case Material: AISI 304 Stainless Steel
• Tip Material: Chemical-resistant PPS (Polyphenylene sulfide)
• Temperature Range: -52°C to +177°C (-62°F to +351°F)
• Pressure Seal: Viton O-ring rated for 50 bar differential
• Bend Radius: Minimum 25.4 mm (1.0 in)
• Thread Engagement: 12 mm maximum for M8x1 threads

Precision Measurement Capabilities

Linear Range: 1.5 mm (60 mils) from 0.25 to 1.75mm
Optimal Gap Setting: 1.0 mm (40 mils)
Scale Factor: 7.87 V/mm (200 mV/mil) ±12.5%
Deviation Tolerance: ±0.06 mm (±2.3 mils)
Target Requirements: Minimum 8.9mm | Recommended 13mm diameter

Installation Specifications

Recommended Torque: Finger tight
Maximum Torque: 0.56 N•m (5 in•lb)
Connector Torque: 5.1 N•m recommended | 7.3 N•m maximum
Field Wiring: Supports up to 305 meters (1,000 feet) with 0.2-1.5mm² shielded triad cable
