3500/20-01-02-00 | Bently Nevada Rack Interface

Core Product Overview

• The Bently Nevada 3500/20-01-02-00 is a Rack Interface Module.
• This module provides communication and control for 3500 monitoring systems.
• It serves as the main interface between the rack and external devices.

Key Technical Specifications

• Manufacturer & Model: Bently Nevada 3500/20-01-02-00
• RIM Type: 01 = Standard RIM for monitoring applications
• I/O Module: 02 = RS232/RS422 Communication Interface
• Agency Approval: 00 = No Special Agency Approvals
• Communication: RS232 and RS422 serial interfaces
• Total Weight: 1.36 Kg (0.91 Kg + 0.45 Kg)
• Origin: Manufactured in the United States of America

Functional Features

• RIM Function: Main interface for 3500 rack operations
• Serial Communication: RS232 and RS422 interface options
• Configuration Port: For system setup and programming
• Monitoring Control: Manages rack communication and data flow
• Compatibility: Standard 3500 series rack installation
• Applications: Standard machinery monitoring systems

Communication & Interface Capabilities

• RS232 Interface: Standard serial communication port
• RS422 Interface: Differential serial communication port
• Data Exchange: Enables configuration and data retrieval
• Protocol Support: Bently Nevada communication protocols
• Connection: To programming tools and external systems
• Documentation: Certificate of Origin (COO) available

Physical Specifications

• Component Weight: Main module 0.91 Kg + interface 0.45 Kg
• Total Weight: 1.36 Kg complete assembly
• Mounting: Installs in 3500 rack interface slot
• Connectors: RS232 and RS422 communication ports
• Construction: Industrial-grade components
• Form Factor: Standard 3500 RIM dimensions

Ordering & Configuration

• Base Model: 3500/20 Rack Interface Module
• First Option: 01 = Standard RIM
• Second Option: 02 = RS232/RS422 I/O Module
• Third Option: 00 = No Agency Approval
• Complete Part Number: 3500/20-01-02-00
• Configuration: Standard monitoring application setup

Installation & Setup

• Install the 3500/20-01-02-00 in the RIM slot of 3500 rack
• Connect RS232 or RS422 cable to programming workstation
• Configure rack parameters using Bently Nevada software
• Test communication with connected monitoring modules
• Verify proper rack initialization and operation

Packaging & Delivery

• One Bently Nevada 3500/20-01-02-00 Rack Interface Module
• Original factory packaging with installation guide
• Shipping via FedEx, UPS, or DHL express delivery
• Certificate of Origin available for international shipments

Frequently Asked Questions

What is the function of this RIM module?

The 3500/20-01-02-00 provides the main interface for 3500 rack communication and control.

What communication interfaces does it have?

It features both RS232 and RS422 serial communication ports.

Is this for standard or hazardous area applications?

This is a Standard RIM for regular monitoring applications.

What does "02" in the model number indicate?

It specifies the RS232/RS422 I/O module interface option.

Where is this product manufactured?

It is manufactured in the United States of America.
