5094-AENTR Flex 5000 Ethernet/IP Adapter

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (15 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 5094-AENTR Flex 5000 Ethernet/IP Adapter

Core Function

This module is the brain for a Flex 5000 I/O station. It connects your sensors and devices to a factory network using Ethernet. It is built for tough industrial jobs where a broken connection means lost money.

Key Technical Specifications

Network Ports: 2 RJ45 Ethernet ports Ethernet Speed: 10/100/1000 Mbps (Auto-sensing) Voltage Input: 18 to 32 V DC Current Draw: 1250 mA at 24V DC Power Inrush: 3200 mA for 100 ms Isolation: 300V continuous (Power to Backplane) Thermal Dissipation: 17.4 BTU/hr Weight: 400 grams (0.88 lbs) Dimensions: 92.7mm H x 94.0mm W x 96.5mm D

Industrial Problem Solver

Stops production line downtime. Its PRP and DLR features create two network paths. If one cable is cut or a switch fails, your machines keep talking without stopping. Perfect for automotive assembly or food processing lines.

Easy Installation Guide

Mounts on a standard DIN rail. Use 22-14 AWG wire for power. The removable terminal block makes wiring fast. Torque screws to 0.4 N-m. Ensure the functional earth is connected with a 2.5mm wire.

Works With

This adapter works with all Flex 5000 I/O modules. Use it to build a custom input/output station for any machine. It talks seamlessly with Allen-Bradley ControlLogix and CompactLogix PLCs.

What You Get

One 5094-AENTR Adapter Module. One removable terminal block (RTB). This product has a 12-month warranty. We ship fast worldwide via FedEx, UPS, or DHL.
