900P01-0501 AC Power Supply for Honeywell Control Systems

Honeywell 900P01-0501 AC Power Supply Module

The 900P01-0501 is an AC power supply module from Honeywell designed for control system applications. It converts 120/240V AC line power to regulated DC voltages for powering control modules and field devices.

Technical Specifications

• Brand & Model: Honeywell 900P01-0501
• Product Type: AC Power Supply Module
• Input Voltage: 90-264 V AC, 47-63 Hz
• Input Current: 1.4 A maximum continuous
• Input Rating: 130 VA
• Output Rating: 58 W
• Hold-up Time: 20 ms @ 115V AC, 60Hz

Electrical Characteristics

• Inrush Current: 40 A peak-to-peak for 120 ms @ 240V AC
• Fuse Protection: Internal non-replaceable fuse
• Test Jacks: 5 V DC and 24 V DC monitoring points
• Wiring: Screw terminals for 0.3-3.3 mm² (#12-22 AWG)

Environmental Specifications

• Ambient Temperature: 0°C to 60°C (T4 rating)
• Designed for industrial control cabinet installation

Key Features

• Wide input voltage range for global compatibility
• Built-in test jacks for voltage verification
• Internal fuse protection
• Sufficient hold-up time for power interruptions
• Screw terminal connections for secure wiring

Typical Applications

• Power supply for Honeywell control system racks
• Field device power distribution
• Control panel main power supply
• Backup power system integration

Packaging & Shipping

• New unit in factory packaging
• Worldwide shipping via FedEx, UPS, DHL

FAQ

• Input voltage range? Wide 90-264V AC, compatible with most global power systems.
• Output power? 58W total output capacity.
• Fuse replaceable? No, internal fuse is non-replaceable.
• Test points? Yes, includes 5V and 24V DC test jacks for verification.
• Temperature rating? Operates from 0°C to 60°C ambient temperature.
