A02B-0047-C920 FANUC CNC Servo Drive Cooling Fan

FANUC A02B-0047-C920 Axial Fan Unit for System 3/5/6 CNC Servo Drives

Technical Specifications

• Brand: FANUC
• Model: A02B-0047-C920
• Series: FANUC System 3/5/6 CNC
• Category: Axial cooling fan motor unit
• Function: Axial airflow for servo drive and CNC control electronics cooling (supplier-reported)
• Communication Interface: None. The unit works as a passive component and carries no built-in communication ports.
• Supply Voltage: FANUC does not publish a rated voltage for this order code. No published spec applies to this early CRT/MDI unit.
• Operating Temperature: FANUC does not publish this value for the System 3/5/6 axial fan.
• Storage Temperature: FANUC does not publish this value for this order code.
• Relative Humidity: 75%RH or less, with no condensation. This figure comes from a family-level reference (GFZ-63523EN/03), and the cross-generation manual does not confirm it for this exact order code.
• Dimensions (H×W×D): FANUC publishes no numerical table and classifies the part simply as an axial fan unit.
• Weight: Approximately 2.15 kg (4.75 lbs). This figure rests on a single supplier report and does not confirm every production batch.
• Lifecycle Status: Legacy. The part serves early FANUC CNC generations and appears mainly in aftermarket channels.

Installation Guide

• Verify that your drive or control cabinet belongs to the System 3/5/6 family before you order this fan.
• Switch off the CNC and isolate the cabinet power before you touch any wiring.
• Photograph the fan mounting and cable routing so reassembly stays straightforward.
• Unbolt the old axial fan and lift it clear of the drive assembly.
• Clean dust from the fan shroud, because blocked airflow raises drive temperatures.
• Fit the A02B-0047-C920 unit, align the mounting holes, and tighten the screws evenly.
• Reconnect the fan leads, restore power, and confirm steady airflow with no vibration.
• Inspect the fan every few months and clear debris to protect drive electronics.

Packaging List

• 1 × FANUC A02B-0047-C920 axial fan unit
• Mounting screws and fasteners as supplied by the seller
• Protective packing for shock-free transit
• Delivery through FedEx, UPS, or DHL

FAQ

• Q: Does FANUC list a supply voltage for the A02B-0047-C920?
  A: No. FANUC publishes no rated voltage for this order code, so check your cabinet wiring diagram before installation.
• Q: What humidity range does this fan unit tolerate?
  A: A family-level manual gives 75%RH or less with no condensation. Confirm this figure against your own cabinet documentation.
• Q: Why do the temperature specs show as unpublished?
  A: FANUC released no operating or storage temperature figures for this System 3/5/6 axial fan. Cabinet-level limits should guide your planning.
• Q: Is the 2.15 kg weight figure reliable?
  A: One supplier reports it as 4.75 lbs. Treat it as a shipping reference rather than a certified specification.
• Q: Does this fan unit offer any communication interface?
  A: No. It runs as a passive cooling component with no built-in ports or fieldbus link.
• Q: How fast do you ship, and which carriers do you use?
  A: We hold brand-new original stock and dispatch within 5 days through DHL, FedEx, or UPS.
• Q: Can I return the fan unit if it does not suit my drive?
  A: Yes. We accept returns within 30 days, so contact us first and we will help you confirm the correct part.
