ABB AO801 Analog Output Module 3BSE020514R1

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (99 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications

Parameter Details
Article Number 3BSE020514R1
Signal Specification 0...20 mA, 4...20 mA
Number of Channels 8
Output Load Maximum 850 Ω
Error Margin 0.1%
Rise Time 10 µs
Update Cycle Time 1 ms
Current Consumption +5 V Modulebus: 70 mA
+24 V External Supply: 200 mA
Rated Insulation Voltage 50 V
Power Dissipation 3.8 W
Maximum Field Cable Length 600 meters (656 yards)
Signal Type Unipolar single-ended
Under/Over Range - / +15%
Stripping Length 6-7.5 mm (0.24-0.30 inches)
Supported Wire Size Solid: 0.05-2.5 mm² (30-12 AWG)
Stranded: 0.05-1.5 mm² (30-12 AWG)
Recommended Torque 0.5-0.6 Nm
Mechanical Dimensions Width: 86.1 mm (3.4”)
Depth: 58.5 mm (2.3”)
Height: 110 mm (4.33”)
Weight: 0.24 kg (0.53 lbs)
Performance Metrics Temperature Drift: Typical 30 ppm/°C, maximum 50 ppm/°C
Error Specification: 0.1%
Output Current Limiting: Designed for short-circuit proof functionality
Isolation Level: Groupwise isolation from ground for enhanced safety
