ABB DA501 Digital I/O Module 1SAP250700R0001

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (15 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

General Information

Specification Details
Extended Product Type DA501
Product ID 1SAP250700R0001
ABB Type Designation DA501
EAN 4016779681094
Catalog Description Digital/analog I/O module. 16 DI: 24VDC. 4 AI: U, I, RTD. 2 AO: U, I. 8 configurable DI/DO: 24VDC 0.5A (DA501)
Long Description DA501: S500 Digital/analog I/O module. 16 DI: 24VDC. 4 AI: U, I, RTD. 2 AO: U, I. 8 configurable DI/DO: 24VDC 0.5A. 1-wire. CN8: 85389091
Product Net Weight 0.121 kg
Product Net Depth / Length 62 mm
Product Net Height 76 mm
Product Net Width 67.5 mm

Technical Specifications

Specification Details
Function 16 DI: 24VDC. 4 AI: U, I, RTD. 2 AO: U, I. 8 configurable DI/DO: 24VDC 0.5A
Analog Inputs 4
Input Signal U, I, RTD, DI
Analog Outputs 2
Output Signal U, I
Resolution Analog Input 13 bit, Analog Output 13 bit
Number of Digital Inputs 16
Number of Digital Configurable I/Os 8
Input Voltage Type DC
Input Voltage (Uin) 24 V DC
Input Current 5 mA
Maximum Input Voltage 30 V
Delay Time (τ) 0.1 … 32 ms
Output Transistor
Output Voltage Type DC
Output Voltage (Uout) 24 V DC
Output Current 0.5 A
Degree of Protection Housing IP20
Rated Voltage (Ur) 24 V DC
Supply Voltage Rated 24 V DC, Range 20.4 … 28.8 V DC
Ambient Air Temperature Operation 0 ... +60 °C, Storage -40 ... +70 °C
