ABB TB825 3BSE036634R1 Multi Mode Optical Media Converter

📌 Brand: ABB

📌 Model: TB825

📌 Series: S800L

📌 Article Number: 3BSE036634R1

✨ Key Features

🔌 Communication Protocol: ModuleBus

⚙️ Master or Slave: Slave

🔧 DIN Rail Mounted: Yes

💡 Multi-Mode Functionality: Supports both plastic and HCS optical fiber conversion

✨ Environmental Specifications

🌡️ Operating Temperature Range: 0 to +55°C (+32 to +131°F)

🌡️ Storage Temperature: -40 to +70°C (-40 to +158°F)

💧 Relative Humidity: 5 to 95%, non-condensing

🌿 Corrosion Protection: ISA-S71.04: G3

📦 Typical Power Consumption: 96 mA at 24V DC

✨ Dimensions & Weight

📏 Width: 85.6 mm (3.37 in.)

📏 Height: 136 mm (5.35 in.) including latch

📏 Depth: 58.5 mm (2.30 in.)

⚖️ Weight: 0.21 kg (0.46 lbs)

✨ Compliance & Certifications

✔️ Protection Class: IP20 (EN 60529, IEC 529)

✔️ CE Marking: Yes

⚓ Marine Certifications: ABS, BV, DNV-GL, LR

✔️ RoHS Compliance: Yes (DIRECTIVE/2011/65/EU, EN 50581:2012)

✔️ WEEE Compliance: Yes (DIRECTIVE/2012/19/EU)

✨ Electrical Safety & Hazardous Location Approvals

⚡ Electrical Safety Certifications: EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201

💥 Hazardous Location Approvals: C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2

✨ Mounting & Temperature Limits

🌡️ Max Ambient Temperature for Vertical Mounting: 40°C (104°F)
