Allen-Bradley | 1746-OB32E DC Output Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (14 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 1746-OB32E 32-Channel Protected DC Output Module

Technical Specifications
Output Configuration 32 channels (2 groups of 16)
Voltage Range 10-30VDC (24VDC nominal)
Current Capacity 0.5A/point @30°C (0.25A @60°C)
Total Module Current 8A maximum
Protection Electronic overload/short-circuit protection
Response Time 0.1ms ON / 1ms OFF
Backplane Power 190mA @5VDC
Termination Color-coded RTB (2x14AWG wires)

Important Safety Features

  • Auto-resetting thermal protection per channel
  • Individual fault detection for each output
  • Millisecond response to overload conditions
  • Note: Does not provide reverse polarity protection
  • Warning: Automatically restores last command after fault

Key Advantages

  • High-density 32-point design saves space
  • LED status indicators for all channels
  • 30G shock resistance for harsh environments
  • 2.5G vibration resistance (10-2000Hz)
  • Wide temperature range (-13 to 140°F)

Recommended Applications

  • Industrial conveyor systems
  • Packaging machine controls
  • Material handling equipment
  • Automated assembly lines
  • Process control systems
