Allen-Bradley 1756-OF8K Analog Output Module 8 Point

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (30 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications for 1756-OF8K

Manufacturer 🏭

Rockwell Automation

General Information ℹ️

Brand: Allen-Bradley

Part Number: 1756-OF8K

Series: ControlLogix

Module Type: Analog Output

Specifications 📊

Number of Pins: 20

Coating: Conformal Coat

Resolution: 15 bits (650 nA/bit @ 21 mA; 320 μV/bit @ 10.4V)

Voltage & Current Ratings ⚡

Backplane Voltage: 5.1V DC, 150 mA max

Output Voltage: -10V to +10V

Output Current: 4-20 mA

Total Backplane Power: 5.8 W

Protection Features 🔒

Overvoltage Protection: 24V DC

Short Circuit Protection: ≤ 21 mA

Drive Capability: Voltage > 2000Ω, Current 0-750Ω

Performance Parameters 📈

Current Draw: 150 mA @ 5.1V; 210 mA @ 24V

Power Dissipation: 5.8 W to 3.15 W

Thermal Dissipation: 16.78 BTU/hr

Settling Time: < 2 ms to 95% final value

Weight: 0.35 kg
