Allen-Bradley 2711P-B12C4A9 PanelView Plus HMI Terminal

Allen-Bradley 2711P-B12C4A9 PanelView Plus 6 - 12.1" HMI Terminal

The Allen-Bradley 2711P-B12C4A9 provides reliable industrial interface performance. This advanced terminal offers robust connectivity and clear visualization for automation systems.

Key Features

• 12.1" color touchscreen display with physical keypad
• 512MB RAM + 512MB Flash memory (79MB user-available)
• Dual communication with EtherNet/IP and RS-232 ports
• Universal power input: 100-240VAC, 50/60Hz operation
• High-performance industrial processor

Display Specifications

• Color TFT LCD technology for clear visuals
• 800×600 pixel resolution for detailed graphics
• 2711P-RL12C2 backlight replacement part
• Resistive touchscreen with physical keypad input
• Wide viewing angles for optimal visibility

Technical Specifications

• High-performance industrial processor
• 512MB RAM and 512MB Flash memory configuration
• Maximum power consumption: 160VA
• Operating temperature: 0°C to 55°C
• Rugged design for industrial environments

Connectivity Options

• 10/100Base-T EtherNet/IP (RJ45 connector)
• RS-232 serial communication port
• Optional 2711P-RN20 Ethernet module support
• MDI/MDI-X auto-crossover capability
• Multiple protocol compatibility

Industrial Features

• Real-time I/O messaging capability
• Application transfer and printing support
• Configurable EtherNet/IP settings
• Rugged construction for harsh environments
• Reliable performance in industrial applications

Physical Details

• Compact dimensions: 20 × 14 × 8 inches
• Lightweight design: 10 lbs (4.5 kg)
• Standard industrial mounting
• FedEx, UPS, and DHL shipping options
• Easy installation and setup

Customer Questions & Answers

• What memory capacity is available?
  The 2711P-B12C4A9 features 512MB RAM and 512MB Flash with 79MB user-available space.
• What power supply is required?
  Universal 100-240VAC, 50/60Hz power input with 160VA maximum consumption.
• What communication ports are included?
  EtherNet/IP (10/100Base-T) and RS-232 serial ports with optional Ethernet module support.
• What are the operating limits?
  It operates reliably in temperatures from 0°C to 55°C for industrial environments.

Applications & Integration

• Industrial process control systems
• Factory automation interfaces
• Machine operation and monitoring
• Production line control stations
• Equipment visualization displays
