Analog Input Module Allen-Bradley 1756-IF16

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (32 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications for 1756-IF16

Basic Information

Manufacturer: Rockwell Automation

Brand: Allen-Bradley

Part Number: 1756-IF16

Module Type: Analog Input Module

Series: ControlLogix

Input Specifications

No. of Inputs: 16 single ended, 8 differential, or 4 high-speed differential

Analog Signals: ±10V, 0-10V, 0-5V, and 0-20 mA

Maximum Input Current, Off-State: 1.5 milliamperes

Performance Characteristics

Settling Time: <80 ms to 5% of full-scale

Scan Time:

  • 16 pt single-ended: 16-488 ms
  • 8 pt differential: 8-244 ms
  • 4 pt high-speed differential: 5-122 ms

Electrical Characteristics

Backplane Current (5.1 VDC): 150 mA

Backplane Current (24 VDC): 65 mA

Total Backplane Power: 2.33 W

Additional Information

Removable Terminal Block (RTB): 1756-TBCH, 1756-TBS6H

Weight: 0.26 kg

Power Consumption: 2.3 Watts

  • Quick Quotes: Receive pricing and availability fast from our dedicated customer service team.
  • Delivery: Expedited, freight, and international shipping available worldwide.
  • Warranty: NexAuto offers a 12-month warranty on all parts purchased from us, in addition to any manufacturer coverage.
  • Returns: 30-day return policy for defective or mismatched parts, ensuring peace of mind.
  • Payment: Flexible options including major credit cards, PayPal, and bank transfers.
  • Custom Calibration: Provide your specifications, and we’ll handle the rest with precision.
