AO801 ABB Analog Output 8ch | 3BSE020514R1

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (11 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

AO801 Analog Output Module – 3BSE020514R1

Key Specifications

Output Channels: 8 unipolar single‑ended (0…20 mA or 4…20 mA)

Resolution: 12‑bit (0.024 mA step)

Accuracy: ≤ 0.1 % full scale (± 0.02 mA)

Update Cycle: 1 ms with 10 µs rise time

Load Capacity: Up to 850 Ω

Isolation: Group‑wise, 500 V AC dielectric test

Power Consumption: 5 V Modulebus 70 mA, external 24 V DC 200 mA

MTBF: 100 000 hours at +40 °C

Service Life: Over 10 years under normal load

Warranty Period: 1 year

Environmental & Safety

Operating Temperature: 0 °C to +55 °C (vertical mounting max +40 °C)

Storage Temperature: -40 °C to +70 °C

Humidity: 5 % to 95 % non‑condensing

Certifications: CE, UL 61010, ATEX Zone 2, C1 Div 2

Marine Approvals: ABS, BV, DNV, LR

Mechanical Details

Modulebus Mounting: S800L rail

Dimensions: W 86.1 mm × D 58.5 mm × H 110 mm

Weight: 0.24 kg

Connector Terminals:

Solid: 0.05–2.5 mm²

Stranded: 0.05–1.5 mm²

Recommended Torque: 0.5–0.6 Nm

Strip Length: 6–7.5 mm
