Bently Nevada 110M7102-01 DIN Rail Power Supply

Bently Nevada 110M7102-01 | DIN Rail Power Supply

Manufacturer: Bently Nevada | Part Number: 110M7102-01 | Type: DIN Rail Mounting Power Supply | Made in: U.S.A.

Key Specifications

• Input Voltage: 100 to 240 V AC
• Output Voltage: 24 V DC
• Output Current: 1.3 Amps
• Output Power: 31.2 Watts
• Mounting: DIN rail
• Operating Temperature: -25°C to +70°C (-13°F to +158°F)

Physical Dimensions

• Width: 22.5 mm (0.89 inches)
• Height: 99 mm (3.90 inches)
• Depth: 107 mm (4.21 inches)
• Compact design: Fits in narrow electrical cabinets

Certifications

• CID2 by UL: Class I, Division 2 certified for hazardous locations
• Suitable for installation in industrial environments
• Meets safety standards for North American hazardous areas

Capacity

• Monitor support: One power supply can drive up to 4 monitors
• Ideal for multi-display monitoring systems
• Reduces number of power supplies needed in control panels

Applications

• 3500 series VGA display modules
• Industrial touch screen monitors
• Control panel power distribution
• Hazardous location installations (Class I, Division 2)

Package Contents

• 110M7102-01 DIN rail power supply unit
• Installation instructions
• Note: DIN rail not included

Shipping Information

• Weight: Approximately 0.3 kg (0.66 lb)
• Packaging: Factory sealed box
• Carriers: FedEx, UPS, DHL (2-5 business days)

Frequently Asked Questions

• Q: How many monitors can this power supply support?
  A: One 110M7102-01 power supply can drive up to 4 monitors simultaneously. This makes it ideal for multi-display monitoring systems in control rooms.
• Q: What is the CID2 certification?
  A: CID2 (Class I, Division 2) by UL certifies this power supply for use in North American hazardous locations where flammable gases or vapors may be present under abnormal conditions.
• Q: What is the operating temperature range?
  A: The power supply operates from -25°C to +70°C (-13°F to +158°F). Suitable for industrial environments including cold or moderately hot locations.
• Q: Does this come with a DIN rail?
  A: No. The power supply is designed for DIN rail mounting, but the DIN rail itself is not included. You need to purchase DIN rail separately based on your panel requirements.
• Q: Is this compatible with 3500/94M displays?
  A: Yes. The 110M7102-01 provides 24V DC output at 1.3A, which is suitable for powering Bently Nevada 3500/94M VGA display modules and other 24V industrial monitors.
