Bently Nevada 200155-23-05 New Accelerometer

Manufacturer: Bently Nevada

Product Number: 200155-23-05

Product Type: Low Frequency Trendmaster Pro Accelerometer

Country of Origin: Made in U.S.A (Certificate of Origin available upon request)

Mounting Stud Option: 23 = 3/8-24 to M16x2.0 thread, 1-3/8 inch hex plate stud for stable and robust installation

Performance & Electrical Specifications:

Sensitivity: 10.2 mV/(m/s²) equivalent to 100 mV/g at 80 Hz ±12%

Measurement Range: ±196 m/s² (±20 g)

Fine Resolution: 24.5 mm/s² (2.5 mg)

Frequency Response: 1.5 to 10,000 Hz (90 to 600,000 cpm), optimized for low-frequency vibration detection

Mounted Resonant Frequency: Greater than 20 kHz (1200 kcpm) for minimal interference

Amplitude Linearity: ±2% over a 1 to 10 g peak acceleration range

Transverse Sensitivity: ≤7%, ensuring precise directional measurement

Settling Time: ≤2000 ms for stabilized output within 5% of bias

Excitation Voltage: 4.7 to 5.5 Vdc for consistent performance

Quiescent Current: Less than 800 μA for low power consumption

Output Bias Voltage: +2.5 Vdc ±0.23 Vdc

Polarity: Positive output when acceleration is directed from base to connector
