Bently Nevada 330103-17-23-05-02-05 8mm Proximity Probe

The 330103-17-23-05-02-05 proximity probe is part of the Bently Nevada 3300 XL vibration monitoring system. It measures shaft vibration and displacement in rotating equipment such as turbines, compressors, and motors. The probe provides stable signal transmission and reliable monitoring performance for industrial machinery protection.

Key Product Overview

• Brand: Bently Nevada
• Model: 330103-17-23-05-02-05
• Series: 3300 XL 8 mm Proximity Probe
• Used for shaft vibration and displacement monitoring.
• Compatible with Bently Nevada 3300 XL Proximitor sensors.
• Miniature coaxial ClickLoc connector with standard cable.
• CSA, ATEX, and IECEx approvals for hazardous locations.

Technical Specifications

• Brand: Bently Nevada
• Model: 330103-17-23-05-02-05
• Minimum unthreaded length: 170 mm.
• Probe case length: 230 mm.
• Total cable length: 0.5 meter.
• Connector type: miniature coaxial ClickLoc connector.
• Probe tip material: Polyphenylene sulfide (PPS).
• Probe case material: AISI 303 or 304 stainless steel.
• Nominal DC resistance: 7.45 Ω ±0.50.

Measurement Performance

• Linear measurement range: 2 mm (80 mils).
• Effective measurement span: 0.25 mm to 2.3 mm.
• Typical output voltage: −1 to −17 Vdc.
• Recommended radial vibration gap: −9 Vdc.

Environmental Limits

• Operating temperature: −52°C to +177°C.
• Probe tip temperature up to +218°C.
• Cable and connector withstand temperatures up to +260°C.
• Humidity variation below 3% ASF during IEC testing.

Installation Guidelines

• Install using the M10 × 1 threaded probe case.
• Maximum thread engagement: 15 mm.
• Set probe gap to approximately −9 Vdc.
• Use shielded triad cable for stable signal transmission.

Packaging Information

• 1 × Bently Nevada 330103-17-23-05-02-05 proximity probe
• Industrial protective packaging
• International shipping via FedEx, UPS, or DHL

FAQ

• What monitoring systems support this probe?
• The probe operates with Bently Nevada 3300 XL Proximitor sensors and vibration monitoring systems.
• What type of equipment commonly uses this probe?
• It is widely used for turbines, compressors, pumps, and other rotating machinery.
• How can measurement accuracy be improved?
• Proper probe gap adjustment and shielded wiring ensure stable and accurate vibration signals.
