Bently Nevada 330104-06-15-10-12-05 3300 XL 8mm Probe

Bently Nevada 330104-06-15-10-12-05 3300 XL Proximity Probe

The 330104-06-15-10-12-05 is an 8 mm diameter proximity transducer from Bently Nevada's 3300 XL monitoring system. This probe is a critical component for measuring vibration and position (radial and axial) on rotating machinery such as turbines, compressors, and pumps.

Technical Specifications

• Brand & Model: Bently Nevada 330104-06-15-10-12-05
• Product Series: 3300 XL Vibration Monitoring System
• Probe Diameter: 8 mm standard for machinery monitoring
• Unthreaded Length (Option 06): 60 mm
• Overall Case Length (Option 15): 150 mm
• Cable Length (Option 10): 1.0 meter (3.3 feet)
• Connector Type (Option 12): Miniature coaxial ClickLoc connector with FluidLoc cable
• Agency Approvals (Option 05): CSA, ATEX, IECEx

Physical Configuration & Options

• The part number is a configurable code defining specific physical attributes:
  330104: Base model for 8 mm Proximity Probes.
  06: Unthreaded probe length of 60 mm.
  15: Overall case (probe body) length of 150 mm.
  10: Total cable length of 1.0 meter.
  12: Miniature ClickLoc connector with FluidLoc oil-resistant cable.
  05: Certification package including CSA, ATEX, and IECEx.
• This configuration is suitable for many standard bearing housing installations.

Key Features

• FluidLoc Cable: Provides enhanced resistance to oils and chemicals commonly found in industrial environments.
• ClickLoc Connector: Miniature coaxial connector with a secure locking mechanism for reliable connections.
• Hazardous Area Certified: ATEX and IECEx approvals allow for use in potentially explosive atmospheres.
• North American Safety: CSA certification ensures compliance with Canadian and US standards.
• Designed for integration with Bently Nevada 3300 XL and compatible monitoring systems.

Function & Application

• Generates an RF signal to measure the distance (gap) between the probe tip and a conductive target (typically a shaft).
• Used for measuring:
  • Shaft Vibration (Radial)
  • Axial Position (Thrust)
  • Eccentricity
  • Differential Expansion
• Essential for predictive maintenance and protecting critical machinery from damage.
• The output is a calibrated voltage proportional to the gap, which is processed by a 3300 XL monitor.

Packaging & Warranty

• Condition: New and original, supplied in factory packaging.
• Factory Warranty: Backed by a standard 12-month manufacturer's warranty.
• Includes the probe assembly with integrated cable and connector.

Packaging & Shipping

• The 330104-06-15-10-12-05 probe ships in its original protective factory box.
• Careful packaging ensures the sensitive probe tip and cable are not damaged.
• Worldwide express shipping via FedEx, UPS, and DHL available.

Frequently Asked Questions (FAQ)

• What is a proximity probe used for? It is a non-contact sensor used to measure the vibration and positional movement of a metal shaft relative to the probe, which is critical for machinery health monitoring.
• What do the length options mean? Unthreaded length (60mm) is the exposed part before threads start. Overall case length (150mm) is the total metal body length. These determine how it fits in the mounting bracket and housing.
• What is the advantage of the FluidLoc cable? It is specifically designed to withstand exposure to lubricating oils and other fluids, preventing cable degradation and signal loss.
• What are ATEX/IECEx approvals? They are certifications for equipment intended for use in explosive atmospheres (e.g., areas with flammable gases or dust), common in oil & gas and chemical plants.
• What monitor does this connect to? It is designed to connect to Bently Nevada 3300 XL series vibration monitors (e.g., 330103, 330180) or compatible system interfaces.
• Is it calibrated? Yes, Bently Nevada probes are factory calibrated to provide a specific output (typically 200 mV/mil or 7.87 V/mm).
• Can the cable be extended? Yes, using approved Bently Nevada extension cables. The total system cable length (probe + extension) must be within the monitor's specification.
