Bently Nevada 330174-00-08-50-02-05 5mm Probe

Compact Vibration and Position Sensor for Tight Spaces

Monitor smaller machinery and high-speed shafts with the Bently Nevada 330174-00-08-50-02-05. This 3300 series 5 mm proximity probe offers precision measurement where space is limited. It is a key component for protection and condition monitoring of compressors, turbines, and motors.

Product Specifications

• Manufacturer & Model: Bently Nevada / 3300 330174-00-08-50-02-05
• Type: 5 mm Proximity Probe (Eddy Current)
• Condition: New Original, Factory Packing
• Warranty: 12 Months
• Thread: M8 x 1.0 mm (Armored)
• Case Length: 0.8 inch (20.3 mm)
• Cable Length: 5.0 metre (16.4 feet)
• Connector: Miniature Coaxial ClickLoc
• Approvals: Multiple Agency (e.g., ATEX/IECEx)

Ordering Code Breakdown

• Model 330174: 3300 5mm Probe, M8 x 1 thread with armor
• Option 00: 0.0 in unthreaded length
• Option 08: 0.8 in overall case length
• Option 50: 5.0 metre cable length
• Option 02: Miniature coaxial ClickLoc connector, standard cable
• Option 05: Multiple agency approvals

Key Features

• Small Diameter: 5mm design fits compact installations and measures smaller shaft targets.
• Extended Cable: 5-meter length reduces need for extensions in many applications.
• Secure Connection: ClickLoc connector ensures reliable, vibration-resistant link.
• Hazardous Area Rated: Built with approvals for use in challenging environments.
• System Ready: Direct compatibility with Bently Nevada 3300/3500 monitoring systems.

Application Notes

• Ideal for measuring vibration and position on smaller diameter shafts and high-speed machinery.
• The armored M8 thread provides robust mounting in high-vibration environments.
• Ensure proper gap setting between probe tip and target during installation.
• Route and secure the long cable properly to avoid damage and electrical noise.

FAQ

• What is the main advantage of a 5mm probe?
  It allows installation in tighter spaces and is suitable for smaller measurement targets compared to standard 8mm probes.
• Is the 5m cable length sufficient?
  Yes, 5 meters is a common longer length, often reducing or eliminating the need for an extension cable.
• What is the ClickLoc connector?
  A proprietary quick-connect locking connector that prevents accidental disconnection.
• Can this probe work with a 3300 XL system?
  Yes, 3300 series probes are compatible with 3300 XL and 3500 monitor frames with appropriate configuration.
• What do "Multiple Approvals" include?
  Typically certifications for hazardous locations (e.g., ATEX, IECEx). Check product label for specifics.
• Is the probe calibrated?Yes, it is factory-calibrated. System sensitivity (mV/mil) must be set in the monitor.
