Bently Nevada 330191-40-75-15-00 8 mm Probes

Bently Nevada 330191-40-75-15-00 Proximity Probes:

🔍 Product Overview

Brand New 3300 XL 8 mm ETR Probe delivers unmatched reliability for industrial monitoring. Features 3/8-24 UNF thread, 4.0" unthreaded length, and 7.5" overall case length. Includes 12-month factory warranty with original packaging.

🚀 Key Enhancements

• TipLoc & CableLoc Technology: Ensures 330N pull strength at probe tip and 270N durability at cable connectors
• 8 mm Rugged Design: Thicker PPS encapsulation increases abuse resistance by 40% vs standard probes
• FluidLoc Option: Prevents oil leakage with IP68-rated seals (available separately)

⚙️ Technical Specifications

• Power Input: -17.5 to -26 Vdc (12 mA max consumption)
• Output Resistance: 50 Ω ±5% | Probe DC Resistance: 7.73 Ω ±0.50 (1.5m length)
• Temperature Range: -55°C to +232°C (EPL Ga/Gc T1 classification)
• Thread Engagement: 0.563" max | Torque Limit: 0.565 N•m

🔧 Physical Construction

• Case Material: AISI 303/304 SST with Viton® O-ring seal
• Cable Options: Standard FEP (1.5m) or PFA (9m max with ETR)
• Weight: 323 g/m | Gold Connectors: 5 µin thickness

✅ Compatibility & Warranty

Optimized for use with Bently Nevada 3300 XL systems. Includes 12-month performance guarantee against manufacturing defects. Note: Pressure testing not included in factory QA.
