Bently Nevada 330195-02-12-05-05 Proximity Probe

Bently Nevada 330195-02-12-05-05 Proximity Probe

This precision proximity probe provides accurate vibration monitoring for critical rotating machinery. The Bently Nevada 330195-02-12-05-05 features reverse mount design and international certifications.

Product Identification

• Manufacturer: Bently Nevada
• Part Number: 330195-02-12-05-05
• Product Type: 3300 XL 8mm Proximity Probe
• Mounting Style: Reverse Mount Configuration
• Origin: Made in U.S.A.
• Weight:0.323kg
• Documentation: Certificate of Origin Available

Model Configuration Breakdown

• 330195 - Proximity Probe Series
• 02 - 8mm Sensing Diameter
• 12 - Reverse Mount Style
• 05 - 0.5 metre Cable Length (1.6 feet)
• 05 - CSA, ATEX, IECEx Certifications

Physical Specifications

• Thread Size: 3/8-24 UNF Standard
• Cable Length: 0.5 metre (1.6 feet)
• Sensing Diameter: 8mm Standard Size
• Mounting: Reverse Mount Configuration
• Construction: Industrial Stainless Steel

Technical Specifications

• Sensing Range: 0-2.0mm (0-80 mils)
• Sensitivity: 200 mV/mil (7.87 V/mm)
• Frequency Response: 0 to 10 kHz
• Linearity: ±1% of full scale
• Temperature Range: -35°C to +177°C (-31°F to +350°F)

Electrical Specifications

• Output Signal: -2 to -18 V DC
• Gap Voltage: -10 to -12 V DC typical
• Cable Type: 95% Copper Braid Shielded
• Connector: Military Style Standard
• Insulation: High Temperature Rated

Quality Assurance

• US Manufacturing Quality
• Certificate of Origin Available
• Individual Calibration Certificate
• Traceability Documentation
• Quality Control Testing

Package Contents

• Proximity Probe Unit
• Calibration Certificate
• Installation Instructions
• Optional COO Document

Warranty & Support

• 12-month manufacturer warranty
• Technical Support Available
• Installation Guidance
• Quality Guarantee
