Bently Nevada 330525-00 Velomitor XA Piezo-velocity Sensor

• Fast shipping
• Return Policy
• Lowest Price
• Help Center 24/7

• Vendor:

  Bently Nevada

• Type:

  Velomitor XA Piezo-velocity Sensor

• Tags Velomitor xa piezo-velocity sensor

• Share
• Tweet
• Pin it

About the Product

Product Overview

Brand & Model

Parameter	Specification
Brand	Bently Nevada
Model	Velomitor XA Piezo-velocity Sensor
Part Number	330525-00
Condition	New & Original in Factory Packing
Factory Warranty	12 Months

Technical Specifications

Parameter	Specification
Sensitivity	3.94 mV/mm/s (100 mV/in/s) ±5%
Frequency Response	4.5 to 2,000 Hz (270 to 120,000 cpm) ±3.0 dB
Temperature Sensitivity	-14% to +7.5% typical over the operating temperature range
Velocity Range	1270 mm/s (50 in/s) peak
Transverse Sensitivity	Less than 5% of sensitivity
Amplitude Linearity	±2% to 152 mm/s (6 in/s) peak
Mounted Resonant Frequency	Greater than 12 kHz
Broadband Noise Floor (4.5 Hz to 2 kHz)	0.004 mm/s (160 µin/s) rms, nominal
Maximum Cable Length	305 metres (1,000 feet) of cable, BN part number 02173007 with no degradation of signal
Weight	156 g (5.5 oz), typical
Diameter	28 mm (1.1 in)
Height	73.1 mm (2.88 in)
Case Material	316L stainless steel
Connector	2-pin Mil-C-26482 hermetically sealed, 316L stainless steel shell
Mounting Torque	45 N-m (33 ft-lb) maximum
Polarity	Pin A goes positive with respect to pin B when the sensor case motion is toward the connector
Cable Bend Radius	1.5-in minimum bend radius
