Bently Nevada 3500/25-01-02-00 Enhanced Keyphasor Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (18 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

New & Original Bently Nevada 3500/25-01-02-00 Enhanced Keyphasor Module

This advanced keyphasor module delivers high-precision timing signals for critical machinery monitoring. The Bently Nevada 3500/25-01-02-00 provides exceptional accuracy across a wide frequency range.

Model Configuration Breakdown

  • 3500/25 - Enhanced Keyphasor Module Series
  • 01 - Single half-height 2-channel card
  • 02 - I/O module with External Terminations
  • 00 - No agency approvals required

Channel Configuration Options

  • 01 - Single half-height 2-channel card
  • 02 - Two half-height 2-channel cards (4 channels total)

I/O Module Type Options

  • 01 - Internal Terminations
  • 02 - External Terminations
  • 03 - Internal Barrier with Internal Terminations
  • 04 - Isolated I/O with Internal Terminations (Magnetic Pickups)
  • 05 - Isolated I/O with External Terminations (Magnetic Pickups)

Physical Specifications

  • Dimensions: 119.9mm × 24.4mm × 256.5mm
  • Imperial Size: 4.72" × 0.96" × 10.10"
  • Weight: 0.34 kg (0.76 lbs)
  • Mounting: Standard 3500 series rack

Environmental Specifications

  • Operating Temperature (Standard): -30°C to +65°C (-22°F to +150°F)
  • Operating Temperature (Internal Barrier): 0°C to +65°C (32°F to +150°F)
  • Storage Temperature: -40°C to +85°C (-40°F to +185°F)
  • Humidity: 95% non-condensing

Speed & Frequency Specifications

  • Input Range: 1 to 1,200,000 cpm (0.017 to 20 kHz)
  • Output Range: 1 to 99,999 cpm (0.017 to 1667 Hz)
  • Max Events/Revolution: Up to 20 kHz maximum

Signal Accuracy Specifications

  • Nonprocessed Signals (0.017-100 Hz): ±1 cpm
  • Nonprocessed Signals (101-500 Hz): ±8 cpm
  • Nonprocessed Signals (501 Hz-20 kHz): ±1% of cpm
  • Processed Signals (0.017-60 Hz): ±1 cpm
  • Processed Signals (61-150 Hz): ±8 cpm
  • Processed Signals (151 Hz-20 kHz): ±1% of cpm

Agency Approval Options

  • 00 - Not required
  • 01 - cNRTLus (Class 1, Div 2)
  • 02 - ATEX/IECEx/CSA (Class 1 Zone 2)
