Bently Nevada | Armored Probe 330104-00-15-10-01-05

ESSENTIAL PROFILE
Bently Nevada 3300 XL 8mm Proximity Probe (P/N: 330104-00-15-10-01-05) combines industrial durability with M10x1 armor threading. U.S.A manufactured and certified for hazardous environments.

PHYSICAL SPECIFICATIONS
◈ Case length: 150 mm ±0.15mm (CNC-machined)
◈ Unthreaded zone: 0 mm (flush-mount capability)
◈ Total probe length: 1.0 m / 3.3 ft (integral cable)
◈ Radial clearance: 1.5mm min (installation guidance)

PERFORMANCE DATA
◈ Temp endurance: -30°C to +100°C continuous operation
◈ Hazardous certs: ATEX II 2G Ex ia IIC T4, IECEx Ex ia IIC T4
◈ Vibration limit: 20 g RMS (10-2000Hz per API 670)
◈ Thread torque: 15 Nm max (304 stainless construction)

CABLE & CONNECTIVITY
◈ Connector type: ClickLoc™ 01 series (IP69K-rated shell)
◈ Cable specs: 3-layer shielding, 22 AWG core
◈ Bending cycles: >500,000 at 25mm radius

COMPLIANCE & RELIABILITY
◈ Certifications: CSA C22.2 No. 0-10, IEC 60079-11
◈ EMI protection: 40 V/m (10kHz-1GHz immunity)
◈ Calibration drift: <0.5%/year (NIST-traceable)

APPLICATION NOTES
Optimized for Zone 1/21 hazardous areas with 8mm±3% linear range. Compatible with 3300/3500/3701 monitoring systems.
