Bently Nevada Position Monitor 3500/45-01-CN

Core Product Overview

• The Bently Nevada 3500/45-01-CN is a Position Monitor module.
• This module provides machinery protection through position monitoring.
• It features country-specific approvals for international installations.

Key Technical Specifications

• Manufacturer & Model: Bently Nevada 3500/45-01-CN
• I/O Module Type: 01 = Position I/O Module with Internal Terminations
• Agency Approval: CN = Country Specific Approvals
• Signal Inputs: Accepts 1 to 4 transducer inputs
• Transducer Support: Proximitor, RPT, DC/AC LVDT, Rotary Potentiometer
• Operating Temperature: -30°C to +65°C (-22°F to +150°F)
• Power Consumption: 7.7W typical (Position I/O)

Functional & Monitoring Features

• Channel Capacity: 1 to 4 independent monitoring channels
• Transducer Types: Proximitor, RPT, DC/AC LVDT, Rotary Potentiometer
• Internal Terminations: Built-in resistors for simplified wiring
• Machinery Protection: Continuous comparison against alarm setpoints
• Input Impedance: 1 MΩ (DC LVDT), 10 kΩ (Proximitor/RPT)
• Global Compliance: Country-specific agency approvals included

Environmental & Electrical Specifications

• Temperature Range: -30°C to +65°C operation
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Humidity Rating: 95% non-condensing operation
• Power Requirements: 7.7W (Position I/O), 8.5W (AC LVDT), 5.6W (Rotary Pot)
• Input Impedance: Varies by transducer type (1MΩ to 200kΩ)
• Dimensions: 24.18 cm x 2.44 cm x 24.13 cm (LxWxH)

Physical Specifications

• Weight: 0.91 Kg total module weight
• Form Factor: Standard 3500 series module size
• Mounting: 3500 rack installation compatible
• Origin: Manufactured in the United States of America
• Documentation: Certificate of Origin (COO) available
• Approvals: Configured for specific country requirements

Ordering & Configuration

• Base Model: 3500/45 Position Monitor
• First Option: 01 = Position I/O Module with Internal Terminations
• Second Option: CN = Country Specific Approvals
• Complete Part Number: 3500/45-01-CN
• Transducer Support: Multiple position transducer types
• Global Use: Approved for specific international markets

Installation & Application

• Install the 3500/45-01-CN module in a 3500 system rack
• Connect up to 4 position transducers of supported types
• Utilize internal terminations for simplified installation
• Configure for specific country regulatory requirements
• Set alarm setpoints for machinery protection monitoring

Packaging & Delivery

• One Bently Nevada 3500/45-01-CN Position Monitor Module
• Original factory packaging with country-specific documentation
• Shipping via FedEx, UPS, or DHL express international
• Certificate of Origin available for customs clearance
• Complete approval documentation for target market

Frequently Asked Questions

How many position inputs does this module support?

The 3500/45-01-CN supports 1 to 4 position transducer inputs.

What does "CN" in the model number indicate?

It means the module has country-specific agency approvals.

What transducer types are compatible?

Proximitor, RPT, DC/AC LVDT, and Rotary Potentiometer transducers.

Does it require external termination resistors?

No, it features convenient internal terminations.

What is the operating temperature range?

It operates from -30°C to +65°C in harsh environments.
