BMXDDI3202K Discrete Input Module Schneider

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (19 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

BMXDDI3202K 32-Channel Digital Input Module

Key Technical Specifications

Input Channels: 32 isolated inputs

Input Voltage: 24 V DC

Input Current: 2.5 mA per point

Input Type: Current sink (logic positive)

Sensor Power Supply: 19-30 V DC

Power Dissipation: 3.9 W

Response Time: 4 ms typical, 7 ms max

Input Impedance: 9600 Ohm

Detailed Performance Data

ON State Current: >= 2 mA

OFF State Current: <= 0.5 mA

Insulation Resistance: > 10 MOhm at 500 V DC

Reliability: 905,000 hours MTBF

Weight: 0.112 kg (0.247 lb)

Fuse Protection: 0.5A fast-blow per group

Reverse Polarity Protection: Yes

Current Consumption: 121 mA at 3.3 V DC

Sensor Compatibility

Works with 2-wire and 3-wire sensors

IEC 60947-5-2 standard compatible

IEC 61131-2 Type 1 compatible

Sensor Fault Detection: < 14 V DC

Sensor OK Detection: > 18 V DC

Package Contents

One BMXDDI3202K input module

Installation documentation

Safety information sheet
