ControlLogix Chassis 1756-A4 Allen-Bradley

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (30 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications for 1756-A4

Product Overview ℹ️

Brand: Allen-Bradley

Part Number/Catalog No: 1756-A4

Series: ControlLogix

Module Type: Chassis

Physical Specifications 📏

Slots: Four (4)

Dimensions: 20 x 20 x 8 inches

Weight: 1.7 pounds (0.75 kilograms)

Power Specifications ⚡

Power Dissipation (Max): 4 Watts

Backplane Current (5 Volts DC): 10 Amps

Backplane Current (24 Volts DC): 2.8 Amps

Backplane Current Ratings 📊

1.2V DC: 1.5A (chassis) / -

3.3V DC: 4A (chassis) / 4A (slot)

5.1V DC: 15A (chassis) / 6A (slot)

24V DC: 2.8A (chassis) / 2.8A (slot)

Additional Features ✨

Available Series: Series A, B, C

Operating Altitude: Up to 2000 meters

Installation Type: Panel Mount
