DI840 3BSE020836R1 ABB Digital Input Redundant or Single

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (97 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications

Brand: ABB
Model: 3BSE020836R1
Type: DI840 Digital Input Module

Input and Electrical Features

Input Channels: 16
I/O Voltage: 24 V DC
Isolation: Groupwise isolated from ground
Input Impedance: 3.3 kΩ
Voltage Range: 19.2 V to 30 V DC

Power and Protection

Power Dissipation: Typ. 2.7 W
Rated Insulation Voltage: 50 V
Dielectric Test Voltage: 500 V a.c.

Environmental and Mechanical Features

Operating Temperature Range: -20°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% non-condensing
Dimensions: 119mm (H) x 45mm (W) x 102mm (D)
Mounting Type: DIN Rail
Weight: 0.25 kg (approx.)
Shipping Weight: 2 kg

Performance Features

Response Time: < 10 ms per channel
MTBF: > 100,000 hours (typical)

  • Quick Quotes: Receive pricing and availability fast from our dedicated customer service team.
  • Delivery: Expedited, freight, and international shipping available worldwide.
  • Warranty: NexAuto offers a 12-month warranty on all parts purchased from us, in addition to any manufacturer coverage.
  • Returns: 30-day return policy for defective or mismatched parts, ensuring peace of mind.
  • Payment: Flexible options including major credit cards, PayPal, and bank transfers.
  • Custom Calibration: Provide your specifications, and we’ll handle the rest with precision.
