Digital DC Input Module Allen-Bradley 1756-IB16

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (30 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications for 1756-IB16

Basic Information

Brand: Allen-Bradley

Part Number: 1756-IB16

Module Type: Digital DC Input Module

No. of Inputs: Thirty-Two (32)

Inputs: 16

Electrical Specifications

Input Voltage: 12-24 Volts DC Sink

Operating Voltage Range: 10-31.2 Volts DC

Maximum Operating Current: 10 milliamperes at 31.2 Volts DC

Minimum Operating Current: 2 milliamperes at 10 Volts DC

Maximum Input Current (Off-State): 1.5 milliamperes

Performance Characteristics

Input Delay Time: 2 milliseconds plus selected filter time

Power Dissipation (Max): 5.1 W @ 60°C (140°F)

Thermal Dissipation: 21.1 BTU/hr @ 60°C (140°F)

Current Specifications

Backplane Current at 24 Volts: 2 milliamperes

Backplane Current at 5.1 Volts: 120 milliamperes

Additional Information

Module Keying: Electronic

Weight: 0.293 kg
