Discrete Output Module GE Fanuc - IC694MDL340

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (33 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Detailed Functional Breakdown:

Module Type: Discrete Output

Full Model: IC694MDL340

Output Channels: 16 points total, grouped as Two (2) groups of Eight (8)

Rated Output Voltage: 120 VAC

Output Voltage Range: 85 to 132 VAC, 47–63 Hz

Output Current: 0.5 A per channel, 3 A per group

Maximum Inrush Current: 20 Amps for 1 cycle

Backplane Current Draw: 315 mA @ 5 VDC when all outputs active

Minimum Load Current: 50 mA

Output Voltage Drop: Max 1.5 V

Off-State Leakage: Max 2 mA

Response Time: ON: Max 1 ms, OFF: Max 1/2 AC cycle

Environmental & Mechanical Data:

Operating Temperature Range: 0°C to 60°C (32°F to 140°F)

Storage Temperature Range: -40°C to +85°C (-40°F to +185°F)

Relative Humidity: 5% to 95% non-condensing

Shock Tolerance: 15G for 11 milliseconds

Vibration Resistance: 10 to 57 Hz @ 0.006 in peak displacement
