DP820 3BSE013228R1 ABB Pulse Counter Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (14 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

ABB General Info

Parameter 📊 Value 🎯
Article Number: 3BSE013228R1
Type: Pulse Counter
Signal Specification: 24 V d.c. (12 - 32 V d.c.)
Number of Channels: 2
HART: No
SOE: No
Redundancy: No
High Integrity: No
Intrinsic Safety: No
Mechanics: S800

ABB Detailed Data

Parameter ⚙️ Value 🛠️
Input Impedance: 2.5 kΩ (DI-input)
Isolation: Individually isolated
Error: Max. frequency error: [320/(MEASTIME in ms)] ppm
Current Limiting: Sensor power can be current limited
Max Field Cable Length: 200 meters (218 yards)
Rated Insulation Voltage: 50 V
Dielectric Test Voltage: 500 V a.c.
Power Dissipation: 2.5 W
Current Consumption +5V: 120 mA

ABB Diagnostics & Environment

Parameter 🧭 Value 📊
Front LED's: P, UP, ST, DI, SY, DO, TP
Process Voltage Supervision: Status indication of supervision
CE Mark: Yes
Electrical Safety: EN 61010-1, UL 61010-1
Operating Temperature: 0 to +55 °C (+32 to +131 °F)
Protection Class: IP20
Relative Humidity: 5 to 95 %, non-condensing

ABB Dimensions

Dimension 🏗️ Value 📏
Width: 45 mm (1.77”)
Depth: 102 mm (4.01”), 111 mm (4.37”) including connector
Height: 119 mm (4.7”)
Weight: 0.15 kg (0.33 lbs.)
