FC-QPP-0002 Honeywell Quad Processor

Honeywell FC-QPP-0002 Quad Processor

Key Features

• Two synchronous processors for efficient control
• Flash memory for system and application programs
• RAM backed up by battery in BKM-0001
• Redundant communication links for fault tolerance
• Data comparators ensure memory consistency
• Watchdog monitors execution time and memory errors
• 24V and 5V input voltage monitoring
• Two outputs for redundant or non-redundant operations
• Four IObus drivers for external device interface
• Diagnostic display and temperature monitoring
• Real-time clock for accurate scheduling

Technical Specifications

• Operating Temp: Outside -5°C to +70°C, Inside -5°C to +85°C
• Storage Temp: -40°C to +85°C
• Weight:1.3kg
• Humidity: 10-95% non-condensing
• Power Supply: 24 V DC (-15% to +30%), max 25 mA; 5 V DC ±5%, max 1.2 A
• Output: +24 V_sd, 15-31 V DC, short circuit proof
• Input: SD high 15-32 V DC, low <4 V, current ~8 mA
• WDout Output Current: 750 mA per output
