FC-TIDI-1624 Input Module | 24V DC Honeywell

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (15 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Honeywell TIDI-1624 Field Termination Assembly Module

The FS-TIDI-1624 and FC-TIDI-1624 modules deliver reliable interface capabilities for non-safe isolated 24V DC input signals. This termination assembly ensures secure connection between field wiring and control system components.

Key Features

  • Sixteen non-safe isolated 24V DC input channels
  • Galvanic isolation between inputs and outputs
  • Reverse polarity protection with series diode
  • Screw terminal connections for field wiring
  • Compatible with SICC-0001/Lx system cables
  • Support for redundant SDI-1624 configurations

Technical Specifications

  • Models: FS-TIDI-1624, FC-TIDI-1624
  • Input Channels: 16 isolated channels
  • Nominal Voltage: 24V DC operation
  • Drop-out Voltage: 2.8V DC minimum
  • Weight:0.6kg
  • Pick-up Voltage: 17.5V DC activation
  • Maximum Voltage: 47.5V DC limit
  • Input Current: 9mA typical at 24V DC
  • Switching Frequency: 20Hz maximum
  • Electrical Life: 1,000,000 operations
  • Mechanical Life: 10,000,000 operations

Isolation & Protection

  • Input to Output: 1000V AC galvanic isolation
  • Input to Input: 1000V AC channel isolation
  • Reverse Polarity: Series diode protection
  • Reverse Voltage: 300V maximum withstand
  • Comprehensive electrical isolation safety

Wiring & Termination

  • Terminal Type: Screw terminals for secure connection
  • Wire Size: 2.5 mm² maximum (AWG 14)
  • Strip Length: 7 mm recommended
  • Torque Setting: 0.5 Nm tightening torque
  • Field wiring interface capability

System Integration

  • Interface for SICC-0001/Lx system cables
  • Connection to SDI-1624 input modules
  • Redundant configuration support
  • Field wiring to control system bridge
  • Industrial automation compatibility

Physical Specifications

  • Dimensions: 265 × 70 × 48 mm (L × W × H)
  • Mounting: DIN EN rails TS32/TS35 × 7.5
  • Compact design for control panel space
  • Industrial-grade construction materials

Certifications & Compliance

  • CE, TUV, UL, CSA safety certifications
  • Industrial standards compliance
  • Global market approval for applications
  • Quality and reliability assurance
