About the Product

Honeywell FC-TPSU-2430 DC/DC Converter Module

Technical Specifications

Type Numbers: FC-TPSU-2430

Approvals: CE, TUV, UL, CSA, FM; Safety Class: SIL3

Input Voltage: 24V DC nominal, 18–36V DC range

Inrush Current: ≤ 4A

Output Voltage: 30V DC ± 0.25V

Output Current: 1A, short-circuit proof

Voltage Ripple: < 0.1 Vrms (0–30 MHz)

Regulation: < 1% load and line

Dimensions: 150 × 70 × 62.3 mm (L × W × H)

DIN Rail: TS32 / TS35 × 7.5

Fuse: 3.15A, 5x20 mm

Termination: Screw terminals, max 2.5 mm² wire, 0.5 Nm torque

Wiring Classification: 80°C minimum

Isolation Voltage: 2000V AC (1 min) between input, output, and relay contact

Operating Temperature: -5°C to +70°C

Storage Temperature: -40°C to +85°C

Cooling: Natural convection

Altitude: ≤2000m

Weight:3kg

Alarm Functions: Dual overvoltage protection, undervoltage LED indicator

Readback Relay Rating: 36V DC / 40 mA, 30V AC / 40 mA
