FC-TSRO-08UNI Honeywell Field Termination Assembly Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (99 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications

Input Parameters

Parameter Details
Nominal Input Voltage 24 V DC
Maximum Input Voltage 36 V DC
Relay Pick-up Voltage 19.2 V DC
Input Current Typically 40 mA at 24 V DC

Output Parameters

Parameter Details
Maximum Output Current 2 A (fused)
Minimum Output Current 1 mA at 5 V
Maximum Switched Load 500 VA (AC)
150 W (DC)
Maximum Output Voltage 250 V AC / 250 V DC
Maximum Switching Frequency 20 Hz
Expected Life Refer to accompanying figure for detailed life expectancy data.

Fuse Specifications

Parameter Details
Fuse Rating 2 A
Fuse Dimensions 5 x 20 mm
Voltage Rating (AC) 250 V
Voltage Rating (DC) 300 V
Manufacturer Littelfuse
Manufacturer Part Number 0213002
Derating Curve Linear from 2 A at 25 °C to 1.9 A at 70 °C ambient temperature.

Termination Details

Parameter Details
Channel Screw Terminals Maximum Wire Diameter: 2.5 mm² (AWG 14)
Strip Length: 7 mm (0.28 in)
Tightening Torque: 0.5 Nm (0.37 ft-lb)
External Power Screw Terminals Maximum Wire Diameter: 16 mm² (AWG 8)
Strip Length: 7 mm (0.28 in)
Tightening Torque: 1.2 Nm (0.88 ft-lb)

Environmental Conditions

Parameter Details
Ambient Temperature Range –5 °C to +60 °C (23 °F to 140 °F)

Relay Contact Ratings

Parameter Details
Maximum Switching Load 250 V AC, 2 A
24 V DC, 2 A
48 V DC, 1 A
110 V DC, 500 mA
