Flame Detector - Honeywell UV Sensor LG1093AC01

LG1093AC01 UV Flame Detector for Gas Turbines

The LG1093AC01 from Honeywell provides reliable flame detection for gas turbine monitoring systems. This UV radiation sensor delivers precise flame condition signals with fast response times. It has established proven performance on General Electric turbines for over three decades.

Product Specifications

• Manufacturer: Honeywell
• Model Number: LG1093AC01
• Product Type: LG Flame Detector
• Cable Length: 9 feet (2.7 meters)
• Sensor Technology: Geiger Mueller phototube
• UV Detection Range: 180-260 nanometer spectrum
• Product Weight: 0.91 kilograms
• Shipping Weight: 3 kilograms

Performance Specifications

• Operating Temperature: -40°C to +176°C range
• Flame Detection Time: 0.1 seconds typical response
• Flame Loss Detection: 0.2 seconds maximum
• Viewing Window: 428 mbar (6.3 psi) pressure rating
• Maximum Cable Distance: 330 meters to amplifier
• System Reliability: 10,000 hours MTBF
• Product Shelf Life: Two years guaranteed

Electrical Specifications

• Amplifier Compatibility: EG1033 series modules
• Power Options: 28 VDC, 20-35 VDC, 115 VAC
• Output Configurations: Transistor or relay contacts
• Circuit Design: Two-conductor armored cable

Key Features

• Solar blind technology for false alarm prevention
• Black body radiation tolerance for accuracy
• Qualified for General Electric turbine applications
• Over one billion documented operating hours
• Fast response for critical safety systems

Certifications & Approvals

• CE Mark compliance for European markets
• ATEX Certification for explosive atmospheres
• Factory Mutual approval for hazardous areas
• Zone 1 and 2 hazardous location rating

Application Areas

• Gas turbine flame supervision systems
• Power generation turbine protection
• Compressor station safety monitoring
• Industrial combustion control systems

Installation Specifications

• Flange Dimensions: 1.73 inch outer diameter
• Flange Width: 0.14 inch mounting surface
• Armored Cable: Two-conductor construction
• Short cable option for compact installations

Compatibility Note

• Not suitable for GE/NP DLE Low-NOx turbines
• Requires special pre-selected models for DLE applications
• Verify specific turbine compatibility before ordering
