GE DS215TCDAG1BZZ01A Digital I/O Board - Mark V System

GE DS215TCDAG1BZZ01A Digital I/O Board

The DS215TCDAG1BZZ01A serves as a sophisticated digital interface in GE's Mark V Speedtronic systems. This I/O Board with firmware processes critical control signals for turbine operations. It features specialized firmware and enhanced connectivity options.

Technical Specifications

• Manufacturer: General Electric
• Part Number: DS215TCDAG1BZZ01A
• Series: Mark V Speedtronic
• Function: Digital I/O Board with Firmware
• Firmware: ZZ01A Optional Package
• Weight:1.5kg
• Revision: B Grade Functional Revision
• Manual: GEH-6195 Documentation
• Origin: United States Manufacturing
• Assembly: Special Mark V Version

Connector Functions

• JP: Power distribution from TCPS board
• JQ: DTBA input signal transmission
• JR: DTBB input signal reception
• JO1: Location 4 output signals
• JO2: Location 5 output signals
• JX1-JX2: IONET communication
• Shielded twisted pair design

Hardware Configuration

• Eight hardware jumper settings
• J1-J8: Factory and IONET functions
• IONET termination resistors
• Board identification configuration
• Stall timer control capability
• Software inversion settings
• Signal conditioning circuits

System Integration

• Mark V Speedtronic control
• Digital I/O cores Q11, Q51
• IONET network communication
• Terminal board connectivity
• Signal processing capability
• Firmware control functions

Signal Processing

• Digital contact input handling
• Relay output signal control
• Solenoid signal management
• Signal timestamp recording
• State change detection
• Software signal inversion

Compatible Components

• DTBA terminal boards
• DTBB input boards
• TCRA output boards
• TCQC processor boards
• CTBA terminal interfaces
• TCPS power supplies

Frequently Asked Questions

• What firmware is included? ZZ01A optional package.
• How many connectors? Multiple specialized connectors.
• What revision level? B grade functional revision.
• IONET communication? Yes, shielded twisted pair.
• Manual reference? GEH-6195 documentation.
• Special assembly? Yes, Mark V special version.

Installation & Support

• Professional installation required
• Jumper configuration necessary
• IONET setup required
• Firmware verification needed
• Technical support available
• Documentation provided
