GE IS210AEDBH4AGD Bridge Interface Card - Mark VI System

GE IS210AEDBH4AGD Bridge Interface Card

The IS210AEDBH4AGD serves as a critical bridge interface component in GE's Mark VI systems. This advanced board supports gas and steam turbine management operations. It integrates seamlessly with GE's CIMPLICITY graphics platform for optimal performance.

Technical Specifications

• Manufacturer: General Electric
• Part Number: IS210AEDBH4AGD
• System: Mark VI Turbine Control
• Board Type: AE DB Bridge Interface
• Connectors: Four 3-position plugs
• Weight:1.5kg
• Transformers: Four Bicron units (B9178)
• Hipot Rating: 5 KVAC insulation level
• Switching Frequency: 10KHz to 500 KHz
• Integrated Circuits: 175+ various types
• Mounting: Nine drilled locations

Component Features

• Multiple capacitors and resistors
• Twenty precision metal film resistors
• Various diodes and transistors
• Encapsulated switch mode transformers
• Pulse transformers for reliability
• Read-only memory chips
• Oscillating circuit chips
• Multiple surface slots for components

System Integration

• Mark VI gas turbine control systems
• Steam turbine management applications
• CIMPLICITY graphics platform compatible
• HMI/Operator interface connectivity
• Industrial turbine control environments

Design Specifications

• High-reliability BIL ratings compliance
• Front and back surface components
• Robust 5 KVAC Hipot level
• Wide frequency operation range
• Multiple board identification codes
• Optimized slot layout design

Frequently Asked Questions

• What system uses this board? GE Mark VI turbine control systems.
• How many connectors does it have? Four 3-position plugs.
• What transformers are included? Four Bicron B9178 models.
• How many integrated circuits? Over 175 various ICs.
• What is the Hipot rating? 5 KVAC insulation level.
• Compatible with which software? GE CIMPLICITY platform.

Installation & Support

• Professional installation recommended
• Manufacturer documentation available
• Technical support provided
• System compatibility verification
• Proper handling procedures required
