GE IS220PPROS1B Emergency Turbine Protection Module

Independent Backup Protection for Critical Turbines

General Electric engineered the IS220PPROS1B for reliable safety systems. This Emergency Turbine Protection I/O Pack works within Mark VIe control systems. It provides independent backup protection when primary control systems require additional safety measures.

Core Technical Specifications

• Manufacturer & Model: General Electric IS220PPROS1B
• Product Type: Emergency Turbine Protection I/O Pack
• Series: Mark VIe Distributed Control System
• Power Supply: 24 VDC operational voltage
• Operating Temperature: -30°C to +65°C
• Dimensions: 14.3 cm height × 23.1 cm width
• Weight: 0.45 kg (approximately 1 lb)

Primary Protection Functions

• Provides backup overspeed protection for turbine systems
• Performs generator synchronization checks to utility bus
• Acts as independent watchdog monitoring primary control
• Monitors three different types of speed input signals
• Detects acceleration, deceleration, and overspeed conditions
• Validates primary speed control for normal operation

System Configurations

• TMR Configuration: Three PPRO packs on SPRO terminal board
• Single Board TMR: Three packs directly on trip board
• Simplex Protection: Single pack for basic backup systems
• Dual Control: Monitors both R and S controller performance
• Communicates via IONet Ethernet to control modules
• Integrates primary and backup systems at trip board level

Compatibility & Terminal Boards

• Direct Mount: SPRO or TREA terminal boards
• Cable Connected: TREG, TREL, TRES via SPRO board
• Trip Boards: TREG (Gas), TREL (Large Steam), TRES (Small Steam), TREA
• DC-37 pin connectors on both cable ends for connections
• Compatible with primary PTUR I/O pack trip systems
• Works with TRPG, TRPL, TRPS, TRPA primary trip boards

Monitoring & Trip Functions

• Monitors primary control performance continuously
• Tracks status and functionality of selected trip board
• Initiates backup trip relays when faults are detected
• Triggers primary control trip as backup safety measure
• Operates completely independent of primary control actions
• Provides comprehensive feedback signal monitoring

Installation Guidelines

• Securely mount SPRO or TREA terminal board first
• For SPRO installations, mount selected trip terminal board
• Connect DC-37 pin cables between SPRO and trip board
• Connect three PPRO modules to TREA or one per SPRO
• Slide threaded posts into terminal board mounting bracket
• Adjust bracket for tight DC-62 pin connector fit

Hardware Features

• Dual independent 10/100 Ethernet ports with auto-negotiation
• Built-in soft-start circuit for controlled power application
• Internal temperature sensor for thermal monitoring
• Hardware reset circuit with watchdog timer
• Electronic board ID reading capability
• Status LED indicators for visual diagnostics

Processor & Operation

• Fast CPU with dedicated flash memory and RAM
• Loads application-specific code from flash memory
• Performs self-test routines during startup sequence
• Verifies board ID matching between components
• Requests network address for Ethernet communications
• Monitors both network paths when dual Ethernet used

Product Availability

• Current Status: In stock for immediate shipment
• New and original General Electric component
• Manufactured in the United States
• Complete with necessary hardware and connectors
• Ships in protective factory packaging

Configuration & Setup

• Configure using ToolboxST* application software
• Customize for specific turbine protection requirements
• Set overspeed thresholds and monitoring parameters
• Define synchronization check criteria
• Establish communication settings for network integration
• Test all protection functions before commissioning

Shipping & Delivery

• Fast processing via FedEx, UPS, and DHL services
• Orders typically ship within 24 business hours
• International shipping available worldwide
• Complete tracking information provided
• Professional packaging ensures component safety

Frequently Asked Questions (FAQ)

What is the main purpose of this module?

• The IS220PPROS1B provides independent backup overspeed protection and generator synchronization checking for turbine systems.

How many packs are typically used in a system?

• A typical TMR system uses three PPRO packs mounted to a simplex protection (SPRO) terminal board.

What trip boards are compatible?

• Compatible with TREG (gas turbine), TREL (large steam), TRES (small steam), and TREA emergency trip boards.

How does it monitor primary control?

• It acts as an independent watchdog, monitoring primary control performance and validating speed operations.

What configuration software is required?

• Configuration is performed using the ToolboxST* application software from General Electric.

What happens during a fault detection?

• When a fault is detected, it trips the backup trip relays on the trip board and initiates a trip on the primary control system.
