High Power Supply Unit | FC-PSU-UNI4825U

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (16 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

FC-PSU-UNI4825U High Power Supply Unit

Power Specifications

Input Voltage: 110-240 V AC (93-253 V AC range)

Output Voltage: 48V DC fixed output

Max Output Current: 25A at 48V DC

Efficiency: >85% at 240V AC, >80% at 120V AC

Power Factor: Close to 1

Ripple Noise: < 75 mVpp

Physical Specifications

Dimensions: 420.5 × 140 × 90 mm (16.57 × 5.51 × 3.54 in)

Weight: 5.7 kg (12.5 lb) including cables

Operating Temperature: -5°C to +70°C (23°F to 158°F)

Storage Temperature: -25°C to +85°C (-13°F to 185°F)

Safety Certifications

Approvals: CE, TUV, UL508, CSA

Isolation: 3750 Vrms input to output

Protection: Dual overvoltage protection

Inrush Current: < 15A

Hold-up Time: 100 ms at full load

Performance Features

Input Frequency: 47-63 Hz range

No Load Consumption: 13W

Input Current: < 7.5A at 240V AC, < 16A at 120V AC

Derating: Starts at 50°C (30W/°C)
