High-Speed Counter Module 5094-HSC Allen-Bradley

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (17 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 5094-HSC High-Speed Counter Module

Essential Technical Data

Input Voltage Range: 18 to 32 Volts DC

Nominal Voltage: 24 Volts DC

On-State Current: 3 milliamps minimum

Voltage Drop: Less than 0.3 Volts DC

Input Current: 8 milliamps maximum per channel

Output Current: 1 amp per channel 3 amps per module

High-Speed Performance

Maximum Count Frequency: 500 kilohertz

Minimum Pulse Width: 125 nanoseconds

Minimum Pulse Separation: 100 nanoseconds

Quadrature Inputs: 2 differential channels (ABZ)

Output Channels: 4 sourcing outputs

Counting Resolution: 32-bit

Electrical Characteristics

Backplane Power: 15 Volts DC

Power Dissipation: 3.5 Watts

Thermal Dissipation: 11.9 BTU per hour

Isolation Voltage: 250 Volts

Overvoltage Protection: 36 Volts maximum

Reverse Voltage Protection: 32 Volts

Physical Specifications

Dimensions: 87mm H x 94mm W x 54mm D

Weight: 143 grams

Enclosure Type: Open style

Wire Size: 22 to 14 AWG

Wire Type: Solid or stranded copper

Environmental Ratings

Operating Temperature: -40 to 70°C

Storage Temperature: -40 to 85°C

Relative Humidity: 5 to 95% non-condensing

Vibration Resistance: 5g @ 10-500 Hz

Shock Resistance: 30g for 11 milliseconds
