Honeywell 900P01-0301 AC Power Supply Module

Honeywell 900P01-0301 AC Power Supply Module

The 900P01-0301 is a compact AC power supply module from Honeywell. It converts AC line power to regulated DC for powering control system components and field devices.

Technical Specifications

• Brand & Model: Honeywell 900P01-0301
• Product Type: AC Power Supply Module
• Input Voltage: 90-264 V AC, 47-63 Hz
• Input Current: 1.4 A maximum
• Output Power: 58 W
• Hold-up Time: 20 ms @ 115V AC

Electrical Features

• Inrush Current: 40 A peak-to-peak for 120 ms
• Fuse Protection: Internal non-replaceable fuse
• Test Jacks: 5 V DC and 24 V DC monitoring points
• Wiring: Screw terminals for 0.3-3.3 mm² (#12-22 AWG)

Physical Dimensions

• Dimensions: 137 mm H x 72.6 mm W (5.4" x 2.86")
• Weight: 0.82 kg (1.81 lbs)
• Compact Design: Space-saving for control cabinets

Key Features

• Wide input voltage for global use
• Built-in test points for verification
• Industrial screw terminal connections
• Compact footprint
• Internal protection circuitry

Typical Applications

• Control system rack power supply
• Field device power distribution
• Control panel main power
• Industrial automation power

Packaging & Shipping

• New unit in factory packaging
• Worldwide shipping via FedEx, UPS, DHL

FAQ

• Input range? 90-264V AC, works with most global power systems.
• Output capacity? 58W total output power.
• Test points? Yes, includes 5V and 24V DC test jacks.
• Dimensions? Compact 137x72.6mm size for tight spaces.
• Fuse replaceable? No, internal fuse is non-replaceable.
