Honeywell FS-IOBUS-CPIO Communication Bus

Honeywell FS-IOBUS-CPIO Communication Bus System

The FS-IOBUS-CPIO provides essential communication between Controller chassis and IO chassis in safety management systems. This vertical IO bus enables reliable data exchange using a robust 34-wire flat cable design.

System Functionality

• Facilitates communication between Controller and IO chassis
• Enables scan, test, and update actions system-wide
• Connects QPP module with various IO modules seamlessly
• Supports vertical IO bus architecture with flat cable technology
• Ensures reliable data transfer across system components

Compatible Chassis Systems

• Controller Chassis: CPCHAS-0001, CPCHAS-0002, CPCHAS-0003
• IO Chassis: IOCHAS-0001S, IOCHAS-0001R, IOCHAS-0002S
• IO Chassis: IOCHAS-0002R, IOCHAS-0003S, IOCHAS-0003R
• Supports both single and redundant chassis configurations
• Compatible with various Safety Manager system sizes

Technical Specifications

• Model: FS-IOBUS-CPIO Communication Bus
• Connector Type: 34-pole latch (female connector)
• Cable Type: 34-wire flat cable construction
• Weight: 0.31 kg lightweight design
• Certifications: UL, CSA approved for industrial use
• Application: Vertical IO bus communication system

Installation & Integration

• Simple connection between Controller and IO chassis
• 34-pole latch connector ensures secure attachment
• Flat cable design for easy routing in control cabinets
• Supports multiple IO chassis in system configurations
• Maintains signal integrity across system components

System Benefits

• Reliable communication for safety-critical operations
• Robust construction for industrial environments
• Easy installation and maintenance access
• Compatible with entire Safety Manager product family
• Supports comprehensive system monitoring functions
