Honeywell LG1093AA25 - ATEX Certified Flame Sensor

LG1093AA25 UV Flame Sensor

The LG1093AA25 from Honeywell delivers reliable flame detection for industrial safety systems. This UV flame sensor provides accurate flame monitoring in demanding environments. It ensures fast response times and maintains stable performance under extreme conditions.

Product Specifications

• Manufacturer: Honeywell
• Model Number: LG1093AA25
• Product Type: UV Flame Sensor
• Cable Length: 16 feet (4.9 meters)
• Mounting: 3/4 inch internal NPT thread
• Cable Type: Teflon shielded with conduit
• Conduit Thread: 1 inch external connection
• Shipping Weight: 3 kilograms

Performance Specifications

• Operating Temperature: -40°C to +176°C range
• Flame Response Time: 0.1 seconds typical detection
• Flame Loss Response: 0.2 seconds maximum
• Viewing Window: 10 bar (150 psi) pressure rating
• Operating Distance: 330 meters sensor to amplifier
• UV Detection Range: 180-260 nanometer spectrum
• Sensor Technology: Geiger Mueller phototube
• MTBF: 10,000 hours reliability rating
• Shelf Life: Two years guaranteed performance

Electrical Specifications

• Amplifier Compatibility: EG1033 series modules
• Voltage Support: 28 VDC standard operation
• Voltage Range: 20-35 VDC flexible power
• AC Voltage: 115 VAC system integration
• Output Options: Transistor or relay contacts

Frequently Asked Questions

What is the cable length of this sensor?

• The sensor comes with a 16-foot cable.
• This equals 4.9 meters in length.
• It suits applications requiring shorter cable runs.

What is the response time for flame detection?

• Flame detection typically occurs within 0.1 seconds.
• Flame loss detection takes maximum 0.2 seconds.
• These fast responses ensure quick safety actions.

What pressure can the sensor withstand?

• The viewing window handles 10 bar pressure.
• This equals 150 pounds per square inch.
• It maintains performance in high-pressure environments.

Which amplifiers are compatible?

• The sensor works with EG1033 amplifier series.
• Multiple output configurations are available.
• Different models suit various control system needs.

What is the operating temperature range?

• The sensor operates from -40°C to +176°C.
• This wide range suits extreme environments.
• It ensures reliability in both hot and cold conditions.

What safety certifications does it have?

• The sensor carries ATEX certification.
• It has Factory Mutual approval.
• CE marking ensures European compliance.
