Honeywell XNX-AMSV-NHNNN Gas Transmitter

Honeywell XNX-AMSV-NHNNN Universal Transmitter

Technical Specifications

• Brand: Honeywell
• Model: XNX-AMSV-NHNNN
• Category: Universal Transmitter / Gas Detector Transmitter
• Series: XNX Universal Transmitter
• Sensor Compatibility: Millivolt (mV) personality board for MPD and Sensepoint high-temperature sensors
• Measurement Range: 0 to 100% LEL for combustible gases (sensor dependent)
• Frequency Response: Fast T90 response suitable for continuous monitoring
• Sensitivity: High sensitivity for mV catalytic bead and infrared sensor inputs
• Linearity: Linear output across the calibrated detection range
• Resolution: Depends on the installed MPD sensor type and configured range
• Temperature Range: -40°C to +65°C (-40°F to +149°F)
• Humidity: 20 to 90% RH non-condensing
• Environmental Tolerance: IP66 rated, painted 316 stainless steel enclosure
• Anti-interference: EMC certified to EN50270:2006 and EN61000-6-4:2007
• Output: 4-20 mA with HART standard; optional relay, Modbus, or Fieldbus
• Power Supply: 16 to 32 VDC
• Approvals: ATEX/IECEx for hazardous area installation
• Cable Entries: 4 x M25 threaded ports

Installation Guide

• Mount the transmitter on a wall or pipe using the integrated mounting lugs.
• Use the optional pipe mount kit for pipes with 50 to 150 mm diameter.
• Connect the mV sensor to the designated terminal strip per the wiring diagram.
• Install certified M25 cable glands on all used conduit entries.
• Seal unused ports with the supplied blanking plugs to maintain IP66 rating.
• Ground the enclosure properly for intrinsic safety and EMC compliance.

Package List

• 1 x Honeywell XNX-AMSV-NHNNN Universal Transmitter
• 1 x Magnetic wand/screwdriver
• 1 x Allen key set
• 3 x Blanking plugs
• 1 x Quick start guide

Shipping Methods

• We ship orders by FedEx, UPS, and DHL for fast international delivery.
• We dispatch in-stock items within 5 days after order confirmation.
• We provide tracking information once the carrier picks up your package.

FAQ

• Q: What sensor types does the XNX-AMSV-NHNNN support?
  A: This model uses the millivolt personality board for MPD catalytic bead and infrared sensors, plus Sensepoint high-temperature sensors.
• Q: What is the measurement range?
  A: It covers 0 to 100% LEL for combustible gases when paired with the appropriate mV sensor.
• Q: Is the enclosure stainless steel or aluminum?
  A: The "S" in the model code indicates painted 316 stainless steel for corrosion resistance.
• Q: What temperature range does this transmitter support?
  A: It operates from -40°C to +65°C, suitable for most industrial environments.
