IC200ALG230 GE VersaMax Analog Input Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (99 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications

General Characteristics

Parameter Value
Channels 4 single-ended, one group
Module ID FFFF9004
Isolation User input to logic and frame ground: 250 VAC continuous, 1500 VAC for 1 minute
Group to group: Not applicable
Channel to channel: None
Backplane Current Consumption 5 V output at 125 mA maximum
External Power Supply None required
Thermal Derating None

Configuration Parameters

Parameter Value
Range Select and Mode Select Configurable via jumpers on the carrier
Diagnostics Internal power loss detection

Voltage Input Characteristics

Parameter Value
Input Voltage Bipolar Mode: ±10 VDC (default)
Unipolar Mode: 0 to 10 V (configurable)
Input Impedance Maximum 126 kΩ
Accuracy 25°C: ±0.3% typical of full scale, ±0.5% maximum
0 to 60°C: ±1% maximum of full scale
Resolution Bipolar Mode: 2.5 mV = 8 counts
Unipolar Mode: 2.5 mV = 8 counts
Filter Response 5 ms
Update Rate 0.4 ms per module
Common Mode Voltage Rejection 30 dB minimum

Current Input Characteristics

Parameter Value
Input Current 4 to 20 mA
Input Impedance Maximum 200 Ω
Accuracy 25°C: ±0.3% typical of full scale, ±0.5% maximum
0 to 60°C: ±1% maximum of full scale
Resolution 4 μA = 8 counts
Filter Response 5 ms
Update Rate 0.4 ms per module
Channel Crosstalk Rejection 30 dB minimum
