IC200MDL743 VersaMax Output Module | GE Fanuc

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (12 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Overview of IC200MDL743

The GE Fanuc Versamax IC200MDL743 is a 5/12/24 VDC negative logic discrete output module with 16 sinking outputs and external power supply support. Shelf life is 1 year.

Technical Breakdown

Model Identification

  • Base Series: IC200
  • Module Suffix: MDL743

Electrical Specifications

  • Output Voltage:
    • TTL Mode: 4.75–5.25 VDC (nominal 5 VDC)
    • 12/24 VDC Mode: 10.2–30 VDC (nominal 12/24 VDC)
  • Current Capacity: 0.5 A per point (max 8 A total)
  • Backplane Draw: 70 mA @ 5 VDC
  • Switching Speed: ON 0.2 ms, OFF 1.0 ms
  • Leakage Current: 0.5 mA @ 30 VDC

Environmental & Mechanical

  • Operating Temperature: –20 °C to 60 °C
  • Storage Temperature: –40 °C to 85 °C
  • Humidity: 5%–95% non-condensing
  • MTBF: 150,000 hours
  • Dimensions: 12.7 mm (W) × 105 mm (H) × 90 mm (D)
  • Weight: 75 g
  • Shelf Life: 1 year

Key Features & Applications

With hot-swap capability and no internal fusing, the IC200MDL743 ensures up to 99.99% uptime for driving lights, relays, and motor starters in harsh industrial environments.

  • Quick Quotes: Receive pricing and availability fast from our dedicated customer service team.
  • Delivery: Expedited, freight, and international shipping available worldwide.
  • Warranty: NexAuto offers a 12-month warranty on all parts purchased from us, in addition to any manufacturer coverage.
  • Returns: 30-day return policy for defective or mismatched parts, ensuring peace of mind.
  • Payment: Flexible options including major credit cards, PayPal, and bank transfers.
  • Custom Calibration: Provide your specifications, and we’ll handle the rest with precision.
