IC200UDD110 | Power Supply | GE Fanuc

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (23 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7
  • Vendor:

    General Electric

  • Type:

    Power Supply

  • Tags Power supply

About the Product

Specifications for IC200UDD110

General Information

Manufacturer: GE Fanuc

Product No.: IC200UDD110

weight：0.46kg

Product Type: 28-Point Micro PLC Power Supply

Inputs & Outputs

Inputs: Sixteen 24Vdc positive logic inputs (4 groups of 4)

Outputs: Twelve transistor outputs, 24Vdc

Load Capacity: 4 outputs at 0.5A; 2 outputs at 1A

Electrical Specifications

Rated Input Voltage: 24 V DC

Input Voltage Range: 0 to 30 V DC

Output Power Supply: +24Vdc, 200 mA maximum

Voltage Range: 12Vdc/24Vdc (24Vdc +10% / -43%)

Response Time: 0.1 ms max (OFF to ON, ON to OFF)

High-Speed Counters

Maximum Counter Frequency: 10 kHz

Input Voltage for ON: 15 V

Input Voltage for OFF: 5 V

Count Registers: 16 bits

Count Pulse Width: 20% to 80% duty cycle at 10 kHz

Isolation & Safety

Isolation Voltage: 1500V RMS (field side to logic side)

Group Isolation Voltage: 500V RMS

Additional Features

Maximum Pulse/PWM Frequency: 5 kHz

Output Load Voltage: Q1-Q4: 12/24 Vdc

Operating Temperature Range: -20°C to 60°C

MTBF: 100,000 hours
