IC693MDL742 ESCP Output Module GE Fanuc

IC693MDL742 ESCP Output Module - GE Fanuc

Channel Configuration: Supports a total of 8 channels per group.

Output Voltage Range: Operates within an output signal range of 12 to 24 volts DC (with a tolerance of +20% to -15%).

Input Voltage Specification: Designed for 12 / 24 VDC nominal input.

Response Times:

• Max on response time: 2 milliseconds
• Max off response time: 2 milliseconds

Voltage Drop: Features a peak output voltage drop of 1.2 volts.

Weight:

Weighs 0.25 kg, making it lightweight and easy to install.

Additional Specifications:

• LED Indicators: Provides visual feedback on the operational status with integrated LED indicators.
• Temperature Range: Operable in a wide temperature range of -20°C to +60°C.
• Short-Circuit Protection: Equipped with short-circuit protection to enhance safety.
• Compliance: Conforms to CE standards for electromagnetic compatibility.
• Mounting Type: Suitable for rack-mounted installation for easy integration.
• Compatibility: Fully compatible with GE Fanuc PLC systems for seamless operation.
