GE Fanuc IC695ACC403 Energy Pack

Model: IC695ACC403

Brand: GE Fanuc

Series: RX3i PACSystem

Description: Energy Pack for CPU Backup

Key Features and Performance:

Voltage Rating: 24V DC

Power Consumption: 72 Watts SELV

Wiring: Requires 18 AWG copper for frame grounding

Mounting Style: DIN Rail mounting compatible for quick installation

Environmental Class: Class I Division 2

Certifications: cULus Listed, CE Marked

Advanced Diagnostic and Functional Capabilities:

Equipped with a "STAT" LED that blinks during the charging cycle

Automatic firmware updates through the connected controller

LED indicator lights up after a successful diagnostics check during power-up

Utilizes non-volatile RAM to preserve system memory contents

Startup diagnostics ensure operational readiness and performance

Additional Specifications:

Operational Temperature Range: 0°C to 60°C (32°F to 140°F)

Storage Temperature: -40°C to 85°C (-40°F to 185°F)

Relative Humidity: 5% to 95%, non-condensing

Altitude Tolerance: Up to 2000 meters without derating

Charging Time: Full charge within 3 minutes

Backup Duration: Supports up to 4 minutes of memory retention

Weight: Approximately 0.45 kg (1.0 lbs)

Shelf Life: 1 year under proper storage conditions
